Description
Single rack, straight design model. Features include an inside drain sump, chemical pumps, prime switches, top mounted controls, automatic start/stop, delime switch and a Poly Pro scrap accumulator. Produces 40 racks/hour and has a 20-1/2” maximum clearance for dishes.
Features & Benefits
- 40 racks / 160 covers per hour.
- 20-1/2″ Door opening for maximum clearance.
- Economical to operate. Uses only 1.09 gallons of water per cycle.
- All stainless steel construction assures long life and years of trouble free operation.
- Power drain saves space, eliminates noisy solenoid and external sump. Drains quickly.
- Top mounted controls include built-in chemical pumps and deliming system that assures proper chemical usage.
- Auto start/stop makes operation safe and easy.
- Integrated scrap tray prevents food soil from entering drain system.
- Airgap fill system.
- Unique sanitizing system provides instant sanitation and eliminates chlorine damage to the machine.
- Stainless Steel impeller offers extended life.
- Stainless Steel scrap tray, long lasting.
- Water inlet comes with built-in strainer, prevents debris from clogging the water valve.
- Dishmachine comes with 2 dishracks
- Self-cleaning pump screen prevents service calls.
- Built-in Poly Pro Scrap Accumulator.
Specifications:
- Model: EST-AH-EXT
- Water Consumption:
- Per Rack: 1.09 GAL
- Per Hour: 43.6 GPH
- Operating Cycle:
- Wash Time (seconds): 53
- Rinse Time (seconds): 15
- Dwell Time (seconds): 22
- Total Cycle (seconds): 90
- Operating Capacity:
- Racks Per Hour: 40
- Wash Tank Capacity: 1.09 GAL
- Pump Capacity: 52 GPM
- Water Requirements:
- Operating Temp: 120 – 140°F
- Water Inlet: 1/2″
- Drain I.P.S.: 2″
- Wash Pump Motor HP: 1
- Dimensions:
- Depth: 25-3/4″
- Width: 25-3/4″
- Total Height with Doors Open: 80-1/2″
- Standard Table Height: 34″
- Max Clearance for Dishes: 20-1/2″
- Standard Dishrack:
- # of Racks: 1
- Dimensions: 20″ x 20″
- Electrical Rating:
- Voltage: 115
- Total Amps: 16
